CYP CLUX-11CA HDMI AUDIO INSERTER

FEATURES • HDMI Audio Insertion - Embeds external audio into HDMI output signals • Multiple Audio Inputs - Supports analogue stereo and optical digital audio • Full HD Video Support - Supports resolutions up to 1920×1080p @60Hz (12-bit) • High Bit Rate Audio Support - Compatible with advanced surround sound formats • HDMI 1.4a Support - Ensures reliable HDMI and DVI compatibility • 3D Signal Support - Compatible with 3D HDMI video formats • Optical Audio Support - Supports LPCM, Dolby Digital and DTS Digital Audio • Extended HDMI Transmission - Supports up to 15m cable distance at 1080p 8-bit or 10m at 12-bit SPECIFICATIONS INPUT PORTS • 1× HDMI (Max. 1920×1080p @60Hz) • 1× Optical Digital Audio • 1× L/R Analogue Audio OUTPUT PORT • 1× HDMI • HDMI Compliance: HDMI 1.4a (DVI 1.0) • HDCP Compliance: HDCP 1.4 • Maximum Resolution: 1920×1080p @60Hz HDMI AUDIO SUPPORT • LPCM 2/5.1/7.1 • Dolby 5.1 • DTS 5.1 • Dolby Digital+ • Dolby TrueHD • DTS-HD Master Audio OPTICAL AUDIO SUPPORT • LPCM 2 • Dolby Digital • DTS Digital Audio 5.1 AUDIO SAMPLING RATES • HDMI up to 192kHz • Optical S/PDIF up to 48kHz OTHER • TMDS Clock Frequency: up to 225MHz • HDMI Cable Distance: Up to 15m at 1080p (8-bit), up to 10m at 1080p (12-bit) • Power Supply: 5V 1A • Power Consumption: 2.7W • Chassis Material: Plastic • Chassis Colour: White • Dimensions: 90.7 × 34 × 85.8mm • Weight: 107g
