Reyee SFP Transceiver RG-NIS-GE-SFP-10KM-SM1310

The Reyee NIS-GE-SFP-10KM-SM1310 is a high-performance Small Form-Factor Pluggable (SFP) transceiver module designed for reliable long-distance data transmission over single-mode fiber (SMF). With a maximum reach of up to 10 kilometers, this module is ideal for applications requiring extended network coverage, such as campus networks, metropolitan area networks (MANs), and long-haul connectivity.

Key Features:

Supports a gigabit speed of 1000 Mbps for seamless data transmission.

Operates at 1310nm wavelength, optimized for long-distance communication.

Offers transmitter power ranging from -9.5 dBm to -3 dBm and receiver sensitivity down to -20 dBm, ensuring excellent signal quality over extended distances.

Easy integration into existing networks with LC connectors and hot-swappable design for minimal downtime.

Operates efficiently in extreme temperatures, from -40°C to +85°C, and within 10% to 90% relative humidity, making it suitable for industrial environments.

Technical Specifications:

Fiber Type: Single-Mode Fiber (SMF)

Core Size: 9/125 μm

Distance Capability: Up to 10 km (32,808 ft)

Connector Type: LC Duplex

Operating Temperature: -40°C to +85°C (-40°F to +185°F)

Digital Diagnostic Monitoring (DDM): Yes
