MERCUSYS 4G LTE 300MBPS ROUTER

FEATURES • 4G LTE Connectivity - Share internet access with up to 32× Wi-Fi devices and enjoy download speeds of up to 150Mbps • Plug-and-Play Setup - Simply insert a SIM card to create your wireless network with no configuration required • 300Mbps Wi-Fi Speeds - Provides fast 2.4GHz wireless connectivity for smooth browsing, streaming and everyday use • Maximum Network Coverage - Four external antennas deliver stable connections and wider wireless coverage • Flexible Router Mode - LAN/WAN port supports wired broadband connection when a 4G network is unavailable SPECIFICATIONS WIRELESS • Network Type: - FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700MHz) - TDD-LTE: B38/B40 (2600/2300MHz) - HSPA+/UMTS: B1/B5/B8 (2100/850/900MHz) • Wi-Fi Class: N300 • Wi-Fi (2.4GHz): 300Mbps • Wireless Standards: IEEE 802.11b/g/n • Frequency: 2.4GHz RECEPTION SENSITIVITY • 11g 54M: -74.5dBm • 11n HT20 MCS7: -73.5dBm • 11n HT40 MCS7: -70.5dBm TRANSMISSION POWER • <20dBm (2.4GHz) WIRELESS SECURITY • WPA-PSK • WPA2-PSK WIRELESS FUNCTIONS • Smart Connect • WPS • Wireless Schedule • Wireless Clients Statistics SOFTWARE OPERATION MODES • 3G/4G Router • Wireless Router CELLULAR MODE • 4G Preferred • 4G Only • 3G Only CELLULAR APN • Data Roaming • Network Search • Profile Create • APN Settings • ISP File Upgrade • PIN Management WAN MODE • Dynamic IP • Static IP • PPPoE • PPTP • L2TP DHCP • Server • DHCP Client List • Address Reservation NAT FORWARDING • ALG • Virtual Server • Port Triggering • UPnP • DMZ PROTOCOLS • IPv4 • IPv6 DATA SETTINGS • Data Statistics • Data Limit GUEST NETWORK • 2.4GHz Guest Network PARENTAL CONTROLS • Time Control • Website Filtering DDNS • Mercusys DDNS • DynDNS • NO-IP SMS • Inbox • New Message • Outbox • Drafts SECURITY • IPv4 SPI Firewall • Access Control • Service Filtering • IP and MAC Binding • IPv6 Firewall SYSTEM SETTINGS • Time Settings • LED Control • Diagnostics • Firmware Upgrade • Backup and Restore • Reboot • Administration • System Log • CWMP Settings DEVICE MANAGEMENT • Mercusys App • Web GUI TR-069 • Supported HARDWARE • Dimensions (W × D × H): 219 × 140 × 32mm • Interfaces: - 1× 10/100Mbps LAN/WAN Port - 3× 10/100Mbps LAN Ports - 1× Nano SIM Card Slot • Antenna: - 2× External 4G LTE Antennas - 2× External Wi-Fi Antennas • Button: WPS / Reset Button • External Power Supply: 9V 0.85A LED • Power • Internet • LAN • Signal (3×) LTE STANDARD • CAT4 • 150Mbps Download / 50Mbps Upload ENVIRONMENT • Operating Temperature: 0~40°C • Storage Temperature: -40~60°C • Operating Humidity: 10~90% RH (Non-Condensing) • Storage Humidity: 5~90% RH (Non-Condensing)
