TP-LINK OMADA 5P GB DUAL BAND WIFI GATEWAY

FEATURES • Dual-Band Wi-Fi 5 - Combined wireless speeds up to 1,167Mbps (300Mbps on 2.4GHz + 867Mbps on 5.0GHz) • Omada SDN Integration - Centralised cloud management via Omada Controller, app or web interface • Multi-WAN Support - up to 3× WAN ports with load balancing for improved uptime and reliability • Advanced VPN - Supports IPsec, PPTP, L2TP and OpenVPN for secure remote access • Gigabit Connectivity - 5× Gigabit ports for high-speed wired networking • Enterprise Security - Firewall, VLAN, QoS and access control for secure and efficient network management SPECIFICATIONS • Wireless Standards: IEEE 802.11a/b/g/n/ac • Frequency: 2.4GHz, 5.0GHz • Wi-Fi Speed: up to 300Mbps (2.4GHz) + 867Mbps (5.0GHz) • Antennas:  - 2.4GHz: 2× 5dBi Fixed Antennas  - 5.0GHz: 2× 5dBi Fixed Antennas • Max. SSIDs: 16× (8× per Band) INTERFACES AND HARDWARE • Ports:  - 1× Gigabit WAN  - 2× Gigabit WAN/LAN  - 2× Gigabit LAN • Button: Reset • Power Supply: 12VDC 1A • Flash: 128MB NAND • DRAM: 256MB DDR3 • Max. Power Consumption: 9W • Mounting: Desktop / Wall Mount • Dimensions (W × D × H): 215 × 117 × 31mm PERFORMANCE • Concurrent Sessions: 50,000 • New Sessions: 2,028/sec • NAT Throughput: up to 900Mbps+ • IPsec VPN Throughput: up to 175.5Mbps • WireGuard VPN Throughput: 71.2Mbps • OpenVPN Throughput: 16.8Mbps WIRELESS FEATURES • Multiple SSIDs: up to 16× • Wireless Features: Band Steering, Load Balance, Airtime Fairness • Transmit Power Control: Adjustable • Advanced Features: VLAN, QoS, Captive Portal, RADIUS NETWORK AND ROUTING • WAN Types: Static IP, Dynamic IP, PPPoE, PPTP, L2TP • DHCP: Server, DHCP Reservation, DHCP Options • VLAN: 802.1Q VLAN • Routing: Static Routing, Policy Routing, RIP, OSPF • NAT: One-to-One, Multi-Net, Virtual Server, Port Triggering VPN • Protocols: IPsec, PPTP, L2TP, OpenVPN, WireGuard • IPsec: up to 6× Tunnels (IKEv1/v2, AES256, SHA) • OpenVPN: Server/Client (up to 18× Tunnels) • WireGuard: Supported • L2TP/PPTP: Server and Client support SECURITY • Firewall: SPI Firewall • Protection: DoS, TCP/UDP/ICMP Flood Defence • Filtering: IP/MAC/URL Filtering • Security: ARP Inspection, IP-MAC Binding • DNS Security: DNSSEC, DoH, DoT MANAGEMENT • Management: Omada Cloud, App, Web UI • Controllers: Hardware and Software Controller Support • Features: Centralised Management, Remote Monitoring, Alerts • Maintenance: Syslog, Diagnostics, Config Backup/Restore ENVIRONMENT • Operating Temperature: 0~40°C • Storage Temperature: -40~70°C • Operating Humidity: 10~90% RH (Non-Condensing) • Storage Humidity: 5~90% RH (Non-Condensing)
