Shelly Dimmer 0/1-10V PM Gen3 Smart Dimming Controller With Power Measurement

Shelly Dimmer 0/1-10V PM Gen3 is a current-sourcing smart dimming controller that interfaces with 0-10V and 1-10V analog dimmable drivers used for LED, motor, or valve control. Built on Shelly's ESP32-C3 platform with 8MB flash, it includes a built-in power meter for instantaneous power and energy readings and supports Wi-Fi, Bluetooth, and weekly scheduling of brightness and transition duration. It is intended for professional dimming installations where the driver itself, not the mains load, is being controlled via a low-voltage 0/1-10V signal.

Specifications

SKU SHELLY DIMMER 0/1-10V GEN3
Brand Shelly
Category Smart Home
Key Specs Channels: 1 (0/1-10V analog output, current-sourcing); Power supply: 110-240V AC 50/60Hz, <1.5W standby; External protection: 16A, tripping characteristic B or C, 6kA interrupting rating; Rated current: 240V AC 13A / 35mA; Power metering: yes, built-in; Connectivity: Wi-Fi, Bluetooth; MCU: ESP32-C3 @ 40MHz, 8MB flash; Dimensions: 38.5 x 43.5 x 17mm; Weight: 28.5g; Mounting: compact enclosure, screw terminals (max torque 0.4Nm)
