LQ BATTERY PACK LIPO4 25.6V 100AH CAN BMS W/MOUNT

FEATURES • High Density Solution: The battery pack is expertly constructed from premium materials and complies with all major safety and performance SPECIFICATIONS • The core cell storage consists of sixteen new Lithium-Ion Phosphate (LFP) prismatic cells manufactured by Hefei Guoxuan Hi-Tech Power Energy Co., Ltd • Guoxuan are the manufacturers of choice for leading German EV brands and well as many other electric vehicle manufacturers • Innovative Battery Management System: The BMS has been designed with the experience of over ten years of battery management involvement • It uses internationally sourced components to ensure consistency, performance and reliability • The firmware is interactively developed and robust • The flexibility of both CAN bus and RS485 communications allows for a wide range of applications • The LCD display allows a clear overview of the battery state of charge and condition without the need for interfacing to a computer SPECIFICATIONS BASIC PARAMETERS • Rated Voltage: 25.6 Volts • Rated Capacity: 100 Amp Hours • Rated Energy: 2560 Watt Hours • Rating: 1C OPERATING PARAMETERS • Operating Voltage Range: 22.4 Volts - 28.0 Volts • Charge Voltage Range: 27.6 Volts - 28.0 Volts (Typical Inverter Bulk/Float Charge can be set to 27.7V) • Cut-Off Voltage: 22.4 Volts (Typical Inverter Cut Off can be set to 23.0V) • Recommended Charge Current: 50 Amps • Maximum Charge Current: 100 Amps • Maximum Discharge Current: 100 Amps PHYSICAL PARAMETERS • Dimensions: 400mm (D) x 550mm (W) x 160mm (H) - Optimised for wall mounting • Weight: 38kg • Communication Ports: RS485 (For programming) , CAN bus, 2x Inverter Battery-Comm / Stacking Ports • Display: LED and LCD with cursor keys for BMS Status and State of Charge • Output Terminal: 2 x Red Amphenol SurLok Positive, 2 x Black Amphenol SurLok Negative • Output Protection: Internal Electronic Circuit Disconnecter ENVIRONMENTAL • Humidity: 5% - 95% Relative Humidity • Charge Temperature Range: 0°C to 45°C • Discharge Temperature Range: -20°C to 60°C • Storage Temperature Range: -20°C to 45°C SERVICE LIFE • Cycle Life: More than 6000 Cycles at 50 Amp Discharge Rate and 80% Depth of Discharge • Hardware Design Life: Fifteen Years • Warranty: Five Years, based on the terms and conditions of the warranty policy CERTIFICATION • Safety: CE, EMC, TUV (IEC62619), UL1973 • Transportation: UN38.3 INSTALLATION • Inverter Integration to BMS: Requires customised cable for each specific inverter brand, refer to manual • Inverter Integration without BMS: Will emulate Lead Acid battery, can be optimised by altering inverter parameters • BMS base protocol compatibility: Voltronic “LIb" BMS protocol / Optional Pylontech BMS protocol • Addressable Parallel Stacking: Battery packs can be paralleled up to sixteen addressable units per solution • Installation Competency: Not consumer installable. Needs to be wired into inverter/UPS by a qualified electrical contractor with appropriate experience.
