Hilook Dome 4MP 30m IR, Built-in Mic Support Motion Detection 2.0

Hilook Dome 4MP 30m IR, Built-in Mic Support Motion Detection 2.0

R 1,849.00 ZAR
R 1,849.00 ZAR
Sale Sold out
Shipping calculated at checkout.
  • Master Card
  • Visa Card
  • Visa Electron
  • Maestro cardMaestro Card
  • Instant Eft Instant Eft
  • MobiCredMobiCred

HIL044-IPC-D140HA-LU

Hilook Dome 4MP 30m IR, Built-in Mic Support Motion Detection 2.0

4 MP Smart Hybrid Light MD 2.0 Fixed Dome Network Camera

  • High quality imaging with 4 MP resolution
  • Support Human and Vehicle Detection
  • Smart Dual-Light: advanced technology with long range
  • Built-in microphone for real-time audio security
  • Water and dust resistant (IP67) and vandal resistant (IK08)
  • Efficient H.265+ compression technology
    • Camera
    • Image Sensor1/3" Progressive Scan CMOS
    • Max. Resolution2560 × 1440
    • Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
    • Shutter Time1/3 s to 1/100,000 s
    • Day & Night IR cut filter
    • Angle Adjustment Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
    • Lens
    • Lens Type Fixed focal lens, 2.8 and 4 mm optional
    • Focal Length & FOV

      2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°

      4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93°

    • Lens MountM12
    • Iris Type Fixed
    • ApertureF1.6
    • DORI
    • DORI

      2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m

      4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m

    • Illuminator
    • Supplement Light TypeIR,White Light
    • Supplement Light Range Up to 30 m
    • Smart Supplement Light Yes
    • IR Wavelength850 nm
    • Video
    • Main Stream

      50 Hz:

      20 fps (2560 × 1440)

      25 fps (1920 × 1080, 1280 × 720)

      60 Hz:

      20 fps (2560 × 1440)

      24 fps (1920 × 1080, 1280 × 720)

    • Sub-Stream

      50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

      60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

    • Video Compression

      Main stream: H.265+/H.265/H.264+/H.264,

      Sub-stream: H.265/H.264/MJPEG

    • Video Bit Rate32 Kbps to 8 Mbps
    • H.264 Type Baseline Profile,Main Profile,High Profile
    • H.265 TypeMain Profile
    • Bit Rate ControlCBR,VBR
    • Region of Interest (ROI)1 fixed region for main stream
    • Audio
    • Audio Type Mono sound
    • Environment Noise Filtering Yes
    • Audio Sampling Rate8 kHz/16 kHz
    • Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
    • Audio Bit Rate64 Kbps (G.711 ulaw/G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
    • Network
    • Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
    • Simultaneous Live View Up to 6 channels
    • API Open Network Video Interface (Profile S, Profile T),ISAPI,SDK
    • Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
    • User/Host

      Up to 32 users

      3 user levels: administrator, operator, and user

    • ClientiVMS-4200,HiLookVision
    • Web Browser

      Plug-in required live view: IE 10, IE 11,

      Local service: Chrome 57.0+, Firefox 52.0+

    • Image
    • Wide Dynamic Range (WDR)120 dB
    • SNR≥ 52 dB
    • Day/Night SwitchDay,Night,Auto,Schedule
    • Image EnhancementBLC,HLC,3D DNR
    • Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
    • Privacy Mask4 programmable polygon privacy masks
    • Interface
    • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
    • Built-in Microphone Yes
    • Event
    • Basic Event Motion detection,video tampering alarm,exception
    • Linkage Upload to FTP,send email,notify surveillance center,trigger capture
    • General
    • Power

      12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

      PoE: IEEE 802.3af, Class 3, max. 7.5 W

    • Material Metal & Plastic
    • DimensionØ121.4 mm × 97.7 mm (Ø4.8" × 3.8")
    • Package Dimension150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
    • Weight Approx. 550 g (1.2 lb.)
    • With Package Weight Approx. 800 g (1.8 lb.)
    • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
    • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
    • Language English, Ukrainian
    • General FunctionHeartbeat,anti-banding,mirror,password protection,password reset via email
    • Approval
    • EMC

      FCC: 47 CFR Part 15, Subpart B,

      CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

      RCM: AS/NZS CISPR 32: 2015,

      IC: ICES-003: Issue 7

    • Safety



      CB: IEC 62368-1: 2014+A11,

      CE-LVD: EN 62368-1: 2014/A11: 2017

    • Environment

      CE-RoHS: 2011/65/EU,

      WEEE: 2012/19/EU,

      Reach: Regulation (EC) No 1907/2006

    • ProtectionIP67: IEC 60529-2013,IK08: IEC 62262:2002
