DS-K4H258S

Hikvision Value Series Magnetic Lock

  • Magnetic lock supports static linear thrust of 280 kg (617 Lbs)
  • Power supply can be 12VDC or 24VDC, (default voltage is 12VDC)
  • Suitable for wooden door, glass door, metal door and fireproof door
  • LED indicator displays door lock status
  • Abrasion-proof materials
    • General
    • Indicator Green: Working Status
    • Power supply12 VDC, 340 mA × 2
    • Working temperature-10 °C to 55 °C (14 °F to 131 °F)
    • Working humidity0 to 95 % (relative humidity)
    • Dimensions

      Lock Body: 238 mm × 45 mm × 25 mm (9.4" × 1.8\" × 1.0\")

      Armature Plate: 182 mm × 38 mm × 12.5 mm (7.2 × 1.5\" × 0.5\")"

    • Weight2.1 kg (4.6 lb)
    • Material

      Shell: hard Anodizing Electroplating Operated

      Lock Body: eco-friendly Nickel Electroplating Operated

      Armature Plate: eco-friendly Zinc Electroplating Operated

    • Thrust Max. 280 kg (617 lb)
    • Door type Single leaf, double leaf, wooden door, glass door, metal door, fireproof door
    • Magnetic Lock/General
    • Unlock method Current Interruption
    • Surface temperature≤ Ambient Temperature +20 °C (68 °F)
