Hikvision L2, Smart Managed, 16 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 2 Gigabit SFP port, 802.3afat, PoE power budget 230W

Hikvision L2, Smart Managed, 16 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 2 Gigabit SFP port, 802.3afat, PoE power budget 230W

R 5,496.00 ZAR
R 5,496.00 ZAR
Sale Sold out
Taxes included. Shipping calculated at checkout.

DS-3E1520P-EI
  • *Please Confirm Stock Availability Before Placing Your Order*
  • Product images Are for Illustrative Purposes Only
  • Honesty And Satisfaction Guaranteed
  • Secure & Safe Online Payments

Hikvision L2, Smart Managed, 16 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 2 Gigabit SFP port, 802.3afat, PoE power budget 230W

Hikvision DS-3E1520P-EI: Hikvision L2, Smart Managed, 16 Gigabit RJ45 PoE ports, 2 Gigabit RJ45 port, 2 Gigabit SFP port, 802.3afat, PoE power budget 230W.

Key Features

  • 16 x gigabit PoE RJ45 port, 2 × gigabit RJ45 port, 2 x gigabit fiber optical port
  • Total PoE power budget 230 W
  • Unified cloud management for security systems
  • Network topology at your fingertips
  • Remote troubleshooting
  • Visualized topology management
  • Up to 300 m long-range PoE transmission
  • 6 kV surge protection

Specifications

General
Shell Metal material
Net Weight 3.2 kg (7.0 lb)
Gross Weight 2.5 kg (5.5 lb)
Dimensions (W × H × D) 440.0 mm × 44.0 mm × 220.8 mm (17.32'' × 1.73'' × 8.69'')
Operating Temperature 0 °C to 45 °C (32 °F to 113 °F)
Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F)
Operating Humidity 5% to 95% (no condensation)
Relative Humidity 5% to 95% (no condensation)
Power Supply 100-240 VAC, 50/60 Hz, Max. 4 A
Max. Power Consumption 250 W
Power Consumption in Idle 20 W
Surge Protection 6 kV
Installation Mode Desk-Mounted,Rack (equipped with mounting ears)
Ports 16 × Gigabit PoE port,2 × Gigabit RJ45 port,2 × Gigabit fiber optical port
MAC Address Table 16 K
Switching Capacity 68 Gbps
Packet Forwarding Rate 50.59 Mpps
Internal Cache 8.4 Mbits
Long Range Ports 1 to 16: up to 300 m. Long range performance may vary depend on camera model or cable condition.
Port Isolation Ports 1 to 20: port isolation mode to improve network security Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
PoE Watchdog Ports 1 to 16: Auto detect and restart the cameras that do not respond.
Link Aggregation Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection. Support static link aggregation. Support 8 aggregation group(s).
QoS QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance. Support port-based priority configuration. Support SP and WRR priority scheduling modes. Support DSCP-based QoS policy.
Loop Prevention Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default. Support 802.1D STP. Support 802.1w RSTP.
VLAN VLAN is used for network scale planning and network health improvement. Support 802.1Q. Configurable VLAN ID from 1-4094. Support Trunk, Access port mode. Support Max. 1024 VLAN.
DHCP Snooping DHCP Snooping can prevent unauthorized connections to DHCP servers from disrupting the network and affecting normal network communication, and only allow DHCP packets from trusted ports to pass through. Disabled by default.
DDM (Digital Diagnostic Monitoring) Support real-time monitoring of key parameters in optical modules, such as operating temperature, operating voltage, operating current, and Rx and Tx optical power.
PoE Standard IEEE 802.3af,IEEE 802.3at
PoE Power Pin End-span: 1/2(-), 3/6(+)
PoE Port PoE: Ports 1 to 16
Max. Port Power 30 W
PoE Power Budget 230 W
Perpetual PoE Supported PoE remains active during system reboot, except in cases of power outage or PSE firmware upgrade.
Chemistry CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)

Product Details

  • Model: DS-3E1520P-EI
  • Brand: Hikvision
  • Hikvision model reference: DS-3E1520P-EI
