SKU:DH-PFM920I-5EU-U-100
Dahua CAT5E 100m Grey
> 100m (328ft)/carton UTP CAT5e, power over Ethernet, compatible with one cable
> High-purity oxygen-free copper conductor material
> Customized PVC outer sheath; ANSI UL CM flame retardant class certified
> Top-notch Quality Commitment for 10 Years
-
Conductor
Material
Oxygen free copper (99.97% purity)
Diameter
0.50 mm ± 0.01 mm (0.0197"±0.0004")
American Wire Gauge
24AWG
Insulation
Material
HDPE
Min. Average Thickness
0.18 mm (0.0071")
Diameter
0.90 mm ± 0.1mm (0.0354"±0.004")
Color (4 Pairs)
Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Rip Cord
Material
Polyester
Specification
500D
Sheath
Material
PVC
Min. Average Thickness
0.50 mm (0.0197")
Diameter
5.10 mm ± 0.30 mm (0.2008"±0.0118")
Color
White
Electrical
Max. DC Resistance of a Single Conductor
9.38Ω/100 m
Min. Insulation Resistance
5000MΩ·km
Max. Mutual Capacitance
5.6nF/100 m
Max. DC Resistance Unbalance
5% (pair intra)
Dielectric Strength
No breakdown with 2.5 kV DC for 2 seconds
Transmission
Characteristic Impedance
100Ω±15Ω
Near End Cross Talk
≥35.30 dB/100 m @100 MHz
Max. Attenuation
22.0 dB/100 m @100 MHz
Return Loss
≥20.1 dB/100 m @100 MHz
Mechanical
Tensile Strength
Sheath≥13.8 MPa, insulation≥16.5 MPa
Elongation at Break
Sheath≥100%, insulation≥300%
Installation Bending Radius
>8 times of outer cable diameter
Conductor Elongation at Break
≥10%
Environmental
Shrinkage of Insulation
≤6%
Color Migration Resistance of Insulation
No migration
Sheath Tensile Strength and Elongation at Break after Aging
≥11.73 MPa, ≥50%
Low Temperature Bending Test
No cracking after the test
Heat Shock Test
No cracking after the test
Operating Temperature
–20°C to +60°C (–4°F to 140°F)
Installation Temperature
0°C to +50°C (32°F to 122°F)
Storage Temperature and Humidity
–10°C to +40°C (14°F to 104°F), <60% (RH)
Security
Vertical Fire Propagation Test
Comply with UL1685 (without smoke measurements)
Packaging
Cable Length
100.0 m (328.08 ft)±1 m (3.28 ft)
Inner Carton Dimensions
250 mm × 111 mm × 250 mm (9.84" × 4.37" × 9.84") (L × W × H)
Net Weight
2.9 kg±0.3 kg (6.39 lb±0.66 lb)
Gross Weight
3.2 kg±0.3 kg (7.05 lb±0.66 lb)
Packaging Dimensions
523 mm × 245 mm × 280 mm
(20.59" × 9.65" × 11.02") (L × W × H)
Packaging Method
100 m/carton, 4 inner cartons in one package
Compliance
Executive Standards
ANSI/TIA 568-C.2-2009, UL444-2008
Certification
Certification
UL CM
