• Dahua 5MP Eyeball 20m IR 3.6mm
1 2

Dahua 5MP Eyeball 20m IR 3.6mm

Dahua 5MP Eyeball 20m IR 3.6mm

R 949.00 ZAR
R 949.00 ZAR
Sale Sold out
Shipping calculated at checkout.
  • Master Card
  • Visa Card
  • Visa Electron
  • Maestro cardMaestro Card
  • Instant Eft Instant Eft
  • MobiCredMobiCred

DH-HAC-HDW1509TLQP-A-LED_3.6mm

Dahua 5MP Eyeball 20m IR 3.6mm

> Max 25 fps@5MP (16:9 video output)

> Super Adapt, 120 dB true WDR, 3D NR

> 24/7 color imaging

> Smart Light+.

> Built-in Mic.

> 30 m illumination distance

> CVI/CVBS/AHD/TVI switchable

> 3.6 mm fixed lens (2.8 mm optional)

> IP67, 12 V DC

> Quick-to-install eyeball saves installation time

Camera

Image Sensor1



5 MP CMOS

Max. Resolution



2880 (H) × 1620 (V)

Scanning System



Progressive

Electronic Shutter Speed



PAL: 1/3 s–1/100,000 s;

NTSC: 1/4 s–1/100,000 s

Min. Illumination



0.001 lux@F1.0 (Color, 30 IRE)

0 lux (Illuminator on)

S/N Ratio



>65 dB

Illumination Distance



30 m (98.43 ft)

Illuminator On/Off Control



Auto/Manual

Illuminator Number



2 (Warm light)

Angle Adjustment



Pan: 0°–360°

Tilt: 0°–78°

Rotation: 0°–360°

Lens

Lens Type



Fixed-focal

Auto Focus



No

Lens Mount



M12

Focal Length



3.6 mm; 2.8 mm

Max. Aperture



F1.0

Field of View



2.8 mm: H: 112°; V: 57°; D: 132°

3.6 mm: H: 88°; V: 46°; D: 104°

Iris Control



Fixed

Close Focus Distance



2.8 mm: 1.6 m (5.25 ft)

3.6 mm: 2.3 m (7.55 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

67.4 m

( 221.13 ft)

27.0 m

( 88.58 ft)

13.5 m

( 44.29 ft)

6.7 m



( 21.98 ft)

3.6 mm

80.0 m

( 262.47 ft)

32.0 m

( 104.99 ft)

16.0 m

( 52.49 ft)

8.0 m



( 26.25 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video

Video Frame Rate



CVI:

PAL: 5M@25 fps; 5M@12.5 fps; 4M@25 fps; 1080p@25 fps

NTSC: 5M@25 fps; 5M@10 fps; 4M@30 fps; 1080p@30 fps

AHD:

PAL: 4M@25 fps

NTSC: 4M@30 fps

TVI:

PAL: 5M 16:9@20 fps; 4M@25 fps

NTSC: 5M 16:9@20 fps; 4M@30 fps

CVBS:

PAL: 960H

NTSC: 960H

Resolution



5M (2880 × 1620); TVI 5M 16:9 (2960 × 1665); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)

Day/Night



Color

BLC



BLC; HLC; WDR; HLC-Pro

WDR



120 dB

White Balance



Auto;Area white balance

Gain Control



Auto/Manual

Noise Reduction



3D NR

Illumination Mode



Smart Light

Defog



Electronic defog

Digital Zoom



4×

Mirror



Yes

Privacy Masking



Off/On (8 areas, rectangle)

Certification

Certifications



CE-LVD: EN 62368-1;

CE-EMC: EN 55032; EN 55035;

Audio

Built-in Mic



Yes

Port

Video Output



Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Alarm Output



1 channel

Power

Power Supply



12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)

Power Consumption



Max 5.5 W (12 VDC, LED on)

Environment

Operating Temperature



–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity



<95% (RH), non-condensing

Storage Temperature



–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity



<95% (RH), non-condensing

Protection



IP67

Anti-corrosion Level



Basic Protection

Structure

Casing Material



Dome (metal + plastic) + plastic enclosure

Product Dimensions



Φ97.1 mm × 94.2 mm (Φ3.82" × 3.71")

Net Weight



0.24 kg (0.53 lb)

Gross Weight



0.37 kg (0.82 lb)

Installation



Wall mount; ceiling mount; vertical pole mount
View full details
