SKU:DH-PFM800-E
Dahua 1 Channel Passive HDCVI Balun
>Real-time transmission over UTP CAT5E/6 cable.
>Passive, no need for power supply.
>With female BNC connector, and pluggable screw terminal connections.
|
Properties |
|
| Transmission Signal |
1 channel |
| Transmission Distance |
HDCVI 720P: max.400m(1312.34ft) 1080P: max.250m(820.21ft) |
| Category Type |
UTP CAT 5E/6 |
|
Video Transmission Properties And Port |
|
| Coaxial Video Connector |
BNC-M |
| Twisted-pair Video Connector |
Push-terminal |
| Compatible Format |
HDCVI/AHD/TVI/CVBS |
| Resolution |
720P/1080P |
| Anti-interference |
＞60db |
|
Protection |
|
| ESD |
1a contact discharge electricity level 3 |
| 1b air discharge electricity level 3 |
|
| Per: IEC61000-4-2 |
|
| Coaxial Cable Connector |
2KV(common-code) Per: IEC1000-4-5 |
| UTP Cable Connector |
2KV(different-code), 4KV(common-code), Per: IEC1000-4-5 |
|
Impedance |
|
| BNC Male |
75 ohms |
| UTP Cable |
100 ohms |
|
Physical Properties |
|
| Dimension(L*W*H) |
180mm*19mm*16mm(7.09”x0.75”x0.63”) |
| Shell |
ABS |
| Color |
Black |
| N.W. |
42g/pair (0.09lb) |
|
Stability |
|
| MTBF |
＞10000h |
|
Environmental |
|
| Operating Temperature |
-10℃~+55℃(14℉~131℉) |
| Storage Temperature |
-20℃~+70℃(-4℉~158℉) |
| Humidity |
0~95%(non-condensing) |
