500M ROLL CAT5E SOLID NETWORK CABLE - GREEN

FEATURES • Category 5e Performance - Supports high-speed Ethernet networking for reliable LAN connectivity • 24AWG Solid Copper Conductors - Ensures stable signal transmission and consistent network performance • Four Twisted Pair Design - Minimises crosstalk and interference for cleaner data signals • Standards Compliant - Meets ISO 11801, TIA/EIA 568-C.2 and EN50173 structured cabling standards • Durable PVC Jacket - Provides protection and flexibility for structured cabling installations • Wide Operating Temperature Range - Reliable performance from -20°C to +70°C SPECIFICATIONS CONDUCTOR • 24AWG Solid Bare Copper (0.511mm) INSULATION • Polyethylene PAIR COLOURS • Blue / White-Blue (0.95mm) • Green / White-Green (0.95mm) • Orange / White-Orange (0.91mm) • Brown / White-Brown (0.91mm) SHEATH • PVC • Nominal OD: 5.2mm FIRE SAFETY RATING • IEC 60332-1 TEMPERATURE RANGE • Installation: 0~50°C • Operational: -20~70°C ELECTRICAL CHARACTERISTICS (AT 20°C) • DC Resistance: 93.8 Ohms/km Max. • Resistance Unbalance: 2% Max. • Mutual Capacitance: 56 nF/km Max. • Capacitance Unbalance: 1000 pF/km Max. • Skew: 450 ns/km Max. • Velocity of Propagation: 68% (0.68 × 3 × 10⁸ m/s) • Characteristic Impedance: 100 Ohms ±15% (1~100MHz)
