Hikvision 8 Port Gigabit Unmanaged POE Switch

Hikvision 8 Port Gigabit Unmanaged POE Switch

R 2,169.00 ZAR
R 2,169.00 ZAR
Sale Sold out
Shipping calculated at checkout.
  • Master Card
  • Visa Card
  • Visa Electron
  • Maestro cardMaestro Card
  • Instant Eft Instant Eft
  • MobiCredMobiCred

DS-3E0510P-E_C

Hikvision 8 Port Gigabit Unmanaged POE Switch

  • Layer 2 network switch designed for video data transmission
  • 8 x 10/100/1000 Mbps ethernet port, 1 x 10/100/1000 Mbps uplink ethernet port and 1 x 10/100/1000 Mbps uplink SFP port
  • IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z network standards available
  • IEEE 802.3 af & at high PoE power supply
  • Store-and-forward switching
  • Safe and reliable using 6 KV high surge protection
  • Plug and play ensures simplicity and convenience.
    • General
    • Shell Metal material, fan-free design
    • Net Weight0.6 kg (1.32 lb)
    • Gross Weight1.4 kg (3.09 lb)
    • Dimensions (W × H × D)217.6 mm × 27.8 mm × 108.55 mm (8.6'' × 1.1'' × 4.3'')
    • Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
    • Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
    • Operating Humidity5% to 95% (no condensation)
    • Relative Humidity5% to 95% (no condensation)
    • Power Supply48 VDC, 2.5 A
    • Max. Power Consumption120 W
    • Power Consumption in Idle10 W
    • Installation Mode Desk-Mounted, Wall-Mounted;
    • Surge Protection6 KV
    • Network Parameters
    • Ports8 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port
    • MAC Address Table4 K
    • Switching Capacity20 Gbps
    • Packet Forwarding Rate14.88 Mpps
    • Internal Cache1.5 Mbits
    • PoE Power Supply
    • PoE StandardIEEE 802.3af,IEEE 802.3at
    • PoE Power PinEnd-span: 1/2(+), 3/6(-)
    • PoE PortPoE: Ports 1 to 8
    • Max. Port Power30 W
    • PoE Power Budget110 W
    • Approval
    • EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
    • Safety UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
    • Chemistry CE-RoHS (2011/65/EU)
